1N NPT Male Hydraulic Fittings

Description:

1N male NPT hydraulic fitting is a straight adapter that is available in plumbing and hydraulic systems.

"*" indicates required fields

Hydraulic NPT fitting comes in a variety of sizes and threads, such as JIC to NPT, NPT to BSP, NPT to metric, and ORFS to NPT thread. Topol Power manufactures a comprehensive range of precision metric adapters to accommodate diverse hydraulic configuration requirements.

PART NO.	THREAD		DIMENSIONS
PART NO.	E	F	A	B	L	S1
1N-02	Z1/8″X27	Z1/8″X27	10.5	10.5	27	12
1N-02-04	Z1/8″X27	Z1/4″X18	10.5	15	31	17
1N-02-06	Z1/8″X27	Z3/8″X18	10.5	16	32	19
1N-04	Z1/4″X18	Z1/4″X18	15	15	35	17
1N-04-06	Z1/4″X18	Z3/8″X18	15	16	37	19
1N-04-08	Z1/4″X18	Z1/2″X14	15	19.5	41.5	22
1N-06	Z3/8″X18	Z3/8″X18	16	16	38	19
1N-06-08	Z3/8″X18	Z1/2″X14	16	19.5	43.5	22
1N-06-12	Z3/8″X18	Z3/4″X14	16	19.5	45.5	27
1N-08	Z1/2″X14	Z1/2″X14	19.5	19.5	47	22
1N-08-12	Z1/2″X14	Z3/4″X14	19.5	19.5	49	27
1N-08-16	Z1/2″X14	Z1″X11.5	19.5	25.5	56	36
1N-12	Z3/4″X14	Z3/4″X14	19.5	19.5	49	27
1N-12-16	Z3/4″X14	Z1″X11.5	19.5	25.5	55	36
1N-12-20	Z3/4″X14	Z1.1/4″X11.5	19.5	26.5	59	46
1N-16	Z1″X11.5	Z1″X11.5	25.5	25.5	61	36
1N-16-20	Z1″X11.5	Z1.1/4″X11.5	25.5	26.5	64	46
1N-16-24	Z1″X11.5	Z1.1/2″X11.5	25.5	27.5	68	50
1N-20	Z1.1/4″X11.5	Z1.1/4″X11.5	26.5	26.5	65	46
1N-20-24	Z1.1/4″X11.5	Z1.1/2″X11.5	26.5	27.5	69	50
1N-24	Z1.1/2″X11.5	Z1.1/2″X11.5	27.5	27.5	69	50
1N-24-32	Z1.1/2″X11.5	Z2″X11.5	27.5	27.5	72	65
1N-32	Z2″X11.5	Z2″X11.5	27.5	27.5	71	65

Click to enlarge

Category: NPT(F) Hydraulic Adapter Tags: NPT, Male, 1N

Description
Package& Shipping

Description

PART NO.	THREAD		DIMENSIONS
PART NO.	E	F	A	B	L	S1
1N-02	Z1/8″X27	Z1/8″X27	10.5	10.5	27	12
1N-02-04	Z1/8″X27	Z1/4″X18	10.5	15	31	17
1N-02-06	Z1/8″X27	Z3/8″X18	10.5	16	32	19
1N-04	Z1/4″X18	Z1/4″X18	15	15	35	17
1N-04-06	Z1/4″X18	Z3/8″X18	15	16	37	19
1N-04-08	Z1/4″X18	Z1/2″X14	15	19.5	41.5	22
1N-06	Z3/8″X18	Z3/8″X18	16	16	38	19
1N-06-08	Z3/8″X18	Z1/2″X14	16	19.5	43.5	22
1N-06-12	Z3/8″X18	Z3/4″X14	16	19.5	45.5	27
1N-08	Z1/2″X14	Z1/2″X14	19.5	19.5	47	22
1N-08-12	Z1/2″X14	Z3/4″X14	19.5	19.5	49	27
1N-08-16	Z1/2″X14	Z1″X11.5	19.5	25.5	56	36
1N-12	Z3/4″X14	Z3/4″X14	19.5	19.5	49	27
1N-12-16	Z3/4″X14	Z1″X11.5	19.5	25.5	55	36
1N-12-20	Z3/4″X14	Z1.1/4″X11.5	19.5	26.5	59	46
1N-16	Z1″X11.5	Z1″X11.5	25.5	25.5	61	36
1N-16-20	Z1″X11.5	Z1.1/4″X11.5	25.5	26.5	64	46
1N-16-24	Z1″X11.5	Z1.1/2″X11.5	25.5	27.5	68	50
1N-20	Z1.1/4″X11.5	Z1.1/4″X11.5	26.5	26.5	65	46
1N-20-24	Z1.1/4″X11.5	Z1.1/2″X11.5	26.5	27.5	69	50
1N-24	Z1.1/2″X11.5	Z1.1/2″X11.5	27.5	27.5	69	50
1N-24-32	Z1.1/2″X11.5	Z2″X11.5	27.5	27.5	72	65
1N-32	Z2″X11.5	Z2″X11.5	27.5	27.5	71	65

Package& Shipping

Package:

We usually use pallets or wooden crates for packaging. Each wooden crate and wooden pallet meets export fumigation requirements. Packaging can also be customised according to customer requirements.

Delivery Time:

It depends on the order volume and if we have them in stock or not. If we have the hose fittings you are looking for in stock, we can ship it within 25-35 day. If we don’t have no in stock, normally it takes 35-55 days for production that depends on the order volume.
