Hydraulic NPT fitting comes in a variety of sizes and threads, such as JIC to NPT, NPT to BSP, NPT to metric, and ORFS to NPT thread. Topol Power manufactures a comprehensive range of precision metric adapters to accommodate diverse hydraulic configuration requirements.
| PART NO. | THREAD | DIMENSIONS | |||||
| E | F | G | A | B | C | S1 | |
| AN-02 | Z1/8″X27 | Z1/8″X27 | Z1/8″X27 | 21 | 21 | 21 | 11 |
| AN-04 | Z1/4″X18 | Z1/4″X18 | Z1/4″X18 | 25.5 | 25.5 | 25.5 | 14 |
| AN-06 | Z3/8″X18 | Z3/8″X18 | Z3/8″X18 | 31 | 31 | 31 | 19 |
| AN-08 | Z1/2″X14 | Z1/2″X14 | Z1/2″X14 | 36.7 | 36.7 | 36.7 | 22 |
| AN-12 | Z3/4″X14 | Z3/4″X14 | Z3/4″X14 | 44 | 44 | 44 | 27 |
| AN-16 | Z1″X11.5 | Z1″X11.5 | Z1″X11.5 | 50 | 50 | 50 | 33 |
| AN-20 | Z1.1/4″X11.5 | Z1.1/4″X11.5 | Z1.1/4″X11.5 | 54.5 | 54.5 | 54.5 | 41 |
| AN-24 | Z1.1/2″X11.5 | Z1.1/2″X11.5 | Z1.1/2″X11.5 | 59.5 | 59.5 | 59.5 | 48 |
