Topol Power can supply all types and sizes of NPSM hydraulic fittings. All of those fittings are available in many types of materials and can be designed for high-performance and durability.
| PART NO | THREAD E | HOSE BORE | DIMENSIONS | |||
| DN | DASH | A | B | S2 | ||
| 21611-04-04 | 1/4″X18 | 6 | 04 | 22 | 4.6 | 19 |
| 21611-04-06 | 1/4″X18 | 10 | 06 | 22 | 4.6 | 19 |
| 21611-06-04 | 3/8″X18 | 6 | 04 | 23 | 6 | 22 |
| 21611-06-05 | 3/8″X18 | 8 | 05 | 23 | 6 | 22 |
| 21611-06-06 | 3/8″X18 | 10 | 06 | 23 | 6 | 22 |
| 21611-08-08 | 1/2″X14 | 12 | 08 | 23.5 | 7.5 | 27 |
| 21611-12-10 | 3/4″X14 | 16 | 10 | 27 | 8.9 | 32 |
| 21611-12-12 | 3/4″X14 | 20 | 12 | 27 | 8.9 | 32 |
| 21611-16-12T | 1″X11.5 | 20 | 12 | 25 | 10.5 | 41 |
| 21611-16-16 | 1″X11.5 | 25 | 16 | 28.5 | 10.5 | 41 |
| 21611-20-20W | 1.1/4″X11.5 | 32 | 20 | 29.5 | 11.2 | 50 |
| 21611-24-20T | 1.1/2″X11 .5 | 32 | 20 | 29.5 | 11.2 | 55 |
| 21611-24-24W | 1.1/2″X11.5 | 40 | 24 | 31.5 | 11.2 | 55 |
| 21611-32-32W | 2″X11.5 | 50 | 32 | 31 | 11.2 | 70 |
